SKU
113990578
Be the first to review this product
ESP32,Wi-Fi,Bluetooth,wireless chip,smallest Wi-Fi BT SoC Module,Lwip,FreeRTOS,Smart Config,AirKiss,FOTA, Internet of things hardware terminal occasions
Email
$3.90
Out of stock
  • 2+: $3.60
  • 50+: $3.40
^ BACK TO TOP

PRODUCT DETAILS

Sorry but this SKU# 113990578 is unavailable from Seeed now.

You can buy it from the original manufacture or other distributors.

The unfilled orders will be shipped out in two batches: 2nd Nov. & 9th Nov.

For the technical support, pls feel free to contact Seeed or ask the original manufacture for help.

Thanks.

Technical details

Dimensions 25.8mm x18mm x2.8mm
Weight G.W 10g
Battery Exclude
Package SMD-38
SPI Flash Default 32Mbit
Bluetooth Bluetooth 4.2 BR/EDR and BLE standards
Wi-Fi 802.11 b/g/n/
Interface  UART、SPI、SDIO、I2C、PWM、I2S、IR、ADC、DAC
On-chip Sensor Hall sensor, Temperature sensor, Capacitive touch sensor
IO Port 22
Frequency Range Support 300~4608000bps,Default 115200bps
Antenna PCB Antenna , Gain 2dBi
Transmit Power  802.11b: 17±2 dBm (@11Mbps) ; 802.11g: 14±2 dBm (@54Mbps) 802.11n: 13±2 dBm (@MCS7)
Receiving Sensitivity CCK, 1 Mbps : -90dBm ; CCK, 11 Mbps: -85dBm; 6 Mbps (1/2 BPSK): -88dBm; 54 Mbps (3/4 64-QAM): -70dBm; MCS7 (65 Mbps, 72.2 Mbps): -67dBm
Power Dissipation [email protected]
Security WPA/WPA2/WPA2-Enterprise/WPS
Power Supply Range 3.0V ~ 3.6V
Operating Temperature -20 ℃ ~ 85 ℃
Storage Environment -40 ℃ ~ 90 ℃ , < 90%RH

Part List

Wi-Fi+BT SoC Module (IPEX block output) 1

ECCN/HTS

ECCN 5A991.b
HSCODE 8517709000
FCC 1
CE 1
